Vector Names Hashing

Source: vignettes/vector_name_hashing.Rmd
vector_name_hashing.Rmd

To speed up named-indexing, cppally implements hashing of vector names via a lazy cache-on-lookup approach. To better understand how this works, we will show what name-indexing in R looks like, how to improve it with hashing, as well as the benefits and limitations of cppally’s inherent lazy-hashing method.

Let’s first load cppally

Indexing into a vector by name is a useful idiom

# Name-value list
x <- list(
  a = 10,
  b = 20,
  c = 30
)

x[["c"]] # Index-by-name
#> [1] 30
x[[3]] # Index-by-location
#> [1] 30

It signifies to those reading the code the exact key we want. Compared to indexing by location, it is resilient to keys changing location.

# If we insert an element between 2 and 3, x[[3]] changes
x <- c(
  x[1:2],
  list(d = 40), # New element
  x[3]
)

x[[3]] # Now 40
#> [1] 40
x[["c"]] # Still the same value
#> [1] 30

Performance of indexing by location versus name

For this we need a large name-value list

set.seed(42)
large <- as.list(sample.int(10^5))
names(large) <- paste0("name_", seq_along(large))

Lookup by location is O(1) and very fast in R, regardless of the index

library(bench)
mark(large[[1]])
#> # A tibble: 1 × 6
#>   expression      min   median `itr/sec` mem_alloc `gc/sec`
#>   <bch:expr> <bch:tm> <bch:tm>     <dbl> <bch:byt>    <dbl>
#> 1 large[[1]]    140ns    160ns  5689315.        0B     569.
mark(large[[length(large)]])
#> # A tibble: 1 × 6
#>   expression                  min   median `itr/sec` mem_alloc `gc/sec`
#>   <bch:expr>             <bch:tm> <bch:tm>     <dbl> <bch:byt>    <dbl>
#> 1 large[[length(large)]]    220ns    250ns  3672229.        0B        0

Since R scans the names each time, lookup by name is O(n) and can be slow if names happen to be near the end of the vector

mark(
    by_name = large[["name_1"]],
    by_index = large[[1]]
)
#> # A tibble: 2 × 6
#>   expression      min   median `itr/sec` mem_alloc `gc/sec`
#>   <bch:expr> <bch:tm> <bch:tm>     <dbl> <bch:byt>    <dbl>
#> 1 by_name       150ns    180ns  5223772.        0B     522.
#> 2 by_index      140ns    161ns  5802491.        0B       0

mark(
    by_name = large[["name_100000"]],
    by_index = large[[100000]]
)
#> # A tibble: 2 × 6
#>   expression      min   median `itr/sec` mem_alloc `gc/sec`
#>   <bch:expr> <bch:tm> <bch:tm>     <dbl> <bch:byt>    <dbl>
#> 1 by_name       510µs    528µs     1873.        0B        0
#> 2 by_index      140ns    160ns  5809388.        0B        0

If we created a hash table of names-values, we could speedup repeated lookups

names_hashtab <- hashtab(size = length(large))
for (i in seq_along(names(large))){
 nm <- names(large)[[i]]
 sethash(names_hashtab, nm, large[[i]])
}

# Confirm it worked
identical(gethash(names_hashtab, "name_10"), large[["name_10"]])
#> [1] TRUE

Let’s now compare all three methods: lookup by location, name and hashed name

mark(
    by_name = large[["name_100000"]],
    by_index = large[[100000]],
    by_hashed_name = gethash(names_hashtab, "name_100000")
)
#> # A tibble: 3 × 6
#>   expression          min   median `itr/sec` mem_alloc `gc/sec`
#>   <bch:expr>     <bch:tm> <bch:tm>     <dbl> <bch:byt>    <dbl>
#> 1 by_name           513µs    527µs     1885.        0B        0
#> 2 by_index          140ns    160ns  5788947.        0B        0
#> 3 by_hashed_name    902ns    942ns   757036.        0B        0

That worked! Extracting the value associated with the last name using the hash table was almost as fast as looking it up by location.

cppally uses this same approach internally, attaching a lazy hash map cache to each r_vector.

Due to R/C++ limitations, the cache cannot survive the R/C++ boundary as we cannot easily attach the cache to the returned SEXP. Therefore instead of a cache-on-1st-lookup approach, which would be most efficient, we implement a cache-on-2nd-lookup approach. This brings certain limitations when writing R functions that use cppally code.

To understand the limitation, it is first crucial to understand how cppally registers C++ functions to R. R can only handle SEXP objects, a generic type that represents any R object.

cppally automatically handles all conversions between cppally classes like r_vector and R’s SEXP. To illustrate this, suppose we have the identity function foo() that accepts an integer vector x and returns the same vector unchanged.

[[cppally::register]]
r_vector<r_int> foo(r_vector<r_int> x){
  return x;
}

The function is then registered to R (via cppally::load_all()) and the following R and C++ code is automatically generated.

Generated R code

foo
function(x) {
  .Call(`_cppally_foo`, x)
}

Generated C++ code

r_vector<r_int> foo(r_vector<r_int> x);
extern "C" SEXP _cppally_foo(SEXP x) {
  BEGIN_CPPALLY
  return cpp_to_r(::foo(as<r_vector<r_int>>(x)));
  END_CPPALLY
}

Looking at the generated R function foo(), we see .Call() is called and is passed the input x. .Call() is the R interface that allows us to pass R objects to C++.

Looking at the generated C++ function - BEGIN_CPPALLY/END_CPPALLY are helpers that run the main code in try/catch blocks to catch any C++ errors and promote them to R errors. In theory, all R errors thrown by cppally are done via R_UnwindProtect which safely runs all C++ destructors on error.

Looking at the innermost function, we can see the expression as<r_vector<r_int>>(x) - this converts the input SEXP from R into a fresh cppally integer vector. The C++ function foo() is then called with that vector, which is then passed to cpp_to_r() - a function that converts C/C++ objects back to SEXP.

The conversions look like this:

SEXP              (R)
  ↓
r_vector<r_int>   (C++)
  ↓
r_vector<r_int>   (C++, via foo())
  ↓
SEXP              (R)

This round-trip from SEXP to r_vector<r_int> and back to SEXP happens every single time foo() is called (which happens via .Call()). Because r_vector is the class that builds and stores the cache, that cache is lost when converting to SEXP and therefore, the hashing approach becomes difficult.

To mitigate the negative performance impacts of this limitation, we implement a hash-on-2nd-lookup approach. This means the first lookup is a linear scan, the second lookup triggers the hash map build before doing a hash lookup. All lookups from the 2nd onwards use the hash map.

Practically speaking this shouldn’t negatively impact performance when doing lookups from R as one would have to write a function that performs exactly two lookups on each call to experience the highest cost penalty, something that while not impossible, is likely uncommon.

In C++, the cache persists across calls since there is no SEXP round-trip. The first lookup is a linear scan, the second builds the hash map, and all subsequent lookups are O(1).

r_int a = x.get("a"); // linear scan
r_int b = x.get("b"); // hash map built + O(1) lookup
r_int c = x.get("c"); // O(1) lookup

Let’s illustrate this by visualising the per call cost as the number of lookups increases, comparing R and cppally.

cpp_source(code = '
#include <cppally.hpp>
using namespace cppally;

[[cppally::register]]
r_vec<r_sexp> do_lookup(r_vec<r_sexp> x, r_str name, int n_iterations){
  r_vec<r_sexp> out(n_iterations);
  for (int i = 0; i < n_iterations; ++i){
    out.set(i, x.get(name));
  }
  return out;
}
')

R equivalent using [[

r_do_lookup <- function(x, name, n_iterations){
  out <- vector("list", n_iterations)
  for (i in seq_along(out)){
    out[[i]] <- x[[name]]
  }
  out
}

The cost of first lookup

Here we are simply comparing the cost of doing a 1st-lookup, in both R and C++

nm <- names(large)[length(large)]

mark(
  cppally_one_lookup = do_lookup(large, nm, 1),
  base_one_lookup = r_do_lookup(large, nm, 1)
)
#> # A tibble: 2 × 6
#>   expression              min   median `itr/sec` mem_alloc `gc/sec`
#>   <bch:expr>         <bch:tm> <bch:tm>     <dbl> <bch:byt>    <dbl>
#> 1 cppally_one_lookup   33.8µs   34.3µs    28093.        0B        0
#> 2 base_one_lookup     511.3µs  526.5µs     1888.    21.6KB        0

While I’m not sure why cppally’s linear scan is faster than R’s, it may be due to the fact that direct data access is used to compare elements instead of STRING_ELT()

The cost of many lookups

We will now plot the per-call cost of doing many repeated lookups to see how many lookups we need to do before we start seeing the benefits of hashing

The plot shows an interesting story - the first lookup (linear scan) sets a baseline cost. The second lookup pays the cost of the hash map build, making it the most expensive per-lookup. From there, each additional lookup amortises the one-time hash build cost over more calls, so the average drops and stabilises well below the first-lookup baseline.

Let’s see how this compares to a pseudo hash-on-1st lookup method. To achieve this we will set the first lookup to be a fast linear scan of the first name which means the rest of real lookups use hashing.

cpp_source(code = '
#include <cppally.hpp>
using namespace cppally;

[[cppally::register]]
r_vec<r_sexp> do_first_lookup_hashed(r_vec<r_sexp> x, r_str name, int n_iterations){
  r_vec<r_sexp> out(n_iterations);

  // Initial lookup as fast linear scan to force all other lookups to be hashed
  static_cast<void>(x.get(x.names().get(0)));

  for (int i = 0; i < n_iterations; ++i){
    out.set(i, x.get(name));
  }
  return out;
}
')

The two lines are overlapping after a few lookups, signifying that there is little penalty to waiting until the 2nd lookup to build the hash map.

Let’s also plot some comparisons comparing repeated hash lookups against repeated linear scan lookups. At the same time we will also use a larger list.

large <- as.list(sample.int(5e05))
names(large) <- paste0("name_", seq_along(large))

cpp_source(code = '
#include <cppally.hpp>
using namespace cppally;

[[cppally::register]]
r_vec<r_sexp> do_linear_lookup(r_vec<r_sexp> x, r_str name, int n_iterations){
  r_vec<r_sexp> out(n_iterations);
  r_vec<r_str> names = as<r_vec<r_str>>(x.names());
  int n = names.length();
  auto *p = names.data(); // Use ptr to allow O2 optimisations here for fair comparison
  for (int i = 0; i < n_iterations; ++i){
    for (int j = 0; j < n; ++j){
      if (unwrap(name) == p[j]){
        out.set(i, x.view(j));
        break;
      }
    }
  }
  return out;
}
')

The best and worst case linear scans are presented for illustrative purposes even though they are not realistic with real data. The most informative comparison is between the trend of the hash lookup cost versus the linear scan (mixed case). We can see that for the first few lookups the linear scan dominates (as expected), but as the number of lookups increases, the hash approach begins to outperform the linear scan (mixed case) and stabilises well below it.

In summary, cppally’s lazy hashing trades a one-time hash build cost for fast repeated lookups. The approach works best in C++, where the cache persists across calls. From R, each call starts fresh, so the benefit is limited to functions that perform multiple lookups within a single call.

Future development

While not explored in this vignette, it is possible to preserve the cache across the R/C++ boundary. By attaching an externalptr to the names_map as an attribute of a custom R vector class, the cache lifetime is tied to the lifetime of the R object (provided that externalptr is kept as an attribute). This may require cppally support for injecting a pre-built cache into a fresh r_vector wrapper, but is otherwise a tractable extension.
